MQT8K
      ---    TPS (Temperature Power Sensor Controller )
      ---    2 Amp. Series for ordinary temperature (-10 °C ~110 °C )
      ---    Life cycle 100K~100K times

Characteristics:

• Operating voltage : AC125V, DC12V/2A; AC250V, DC24V/1.3A
• Maximum operating voltage : AC250V max., DC48V max
• Temperature setting range : - 10 °C ~110 °C
• Differential : A rank(3 +/-1), B rank(4.5+/-1.5), C rank(6.5+/-1.5), D rank(10+/-2)
• Temperature setting tolerance : +/-3 when the temperature is below 50°C

Feature:

• Standard model of the 2 Amp. series with mounting holes.
• With a 150mm lead
• Size: 44 x 12.5 x 6.4 mm
